•Operating Parameters
Current Rating : < 52A
Voltage Rating : AC 220V
Contact resistance : < 10mΩ
Dielectric resistance : 500mΩ at DC500V
Standing voltage : 3KV Under normal temperature

•Material- ROHS Environmental protection material
Cable Type : PVC, Rubber, Silicon
Shell material : Flame-resistant/anti-UV nylon (PA66)
Compressed Socket : Brass
Crown Spring : beryllium copper
pin : brass plated 4U
Seal-O-Ring : Silicon

•Property
Waterproof Rating : IP68
Cable OD Rating : OD≤ 14.0mm
Times of plug/pull : Above 1500 times
Operating temperature : -45⁰C ~ +105⁰C
Humidity : 90% + 40 ⁰C
