•Operating Parameters
Current Rating : 20A
Voltage Rating : 250V AC
Resist-Electric Strength : 500V AC/min
Times of plug/pull : Above 3000 times
Cable OD Rating : OD≤14.0mm

•Material- ROHS Environmental protection material
Cable Type : PVC, PU, Rubber, Silicon
Shell material : Flame-resistant/anti-UV nylon(PA66)
                       RL94V-0
Compression connection type pinhole : Brass
Seal-O-Ring : Silicon

•Property
Contact resistance : ≤10mΩ
Dielectric resistance : 500mΩ at DC500V
Standing voltage : 3KV Under normal temperature
Operating temperature : -45℃~+105℃
Humidity : 90%+40℃
Waterproof Rating : IP68
