Parameter

Symbol

Maximum Rating

Unit

Power Dissipation

Pd

3.8

W

Peak Forward Current
(300pps, 10μs pulse)

IFP

5

A

DC Forward Current

-

1

A

Reverse Voltage Per Chip

VR

5

V

Operating Temp.

Topr

–40  ~ ＋85

℃

Storage Temp.

Tstg

–55  ~ ＋100

℃

Infrared Soldering Condition

-

260°C for 10 Seconds Max.

Parameter

Symbol

Min.

Typ.

Max

Unit

Condition

Forward Voltage

VF

-

3.3

3.8

V

IF=1A

Radiant Intensity

IE

350

500

-

mW/sr

Total Radiant Flux

Фe

-

950

-

mW

Peak Emission Wavelength

λpeak

-

810

-

nm

Spectral Line Half--Width

Δλ

-

50

-

nm

Viewing Angle

2θ1/2

-

90

-

deg

-

Reverse Current

IR

-

-

10

μA

VR=5V
